Aircon Installation

Proper installation ensures the longevity and optimal cooling performance of your air conditioning system. It also helps you save on your energy bills in the long run. Read on and find out the steps for installing a window aircon and a split-type air conditioner.

Aircon installation for a window-type AC unit

Most window-type air conditioners work for small rooms with double-hung windows that have a top or bottom sash which can be adjusted. The bottom sash can either be raised or lowered, depending on the size of the window AC. Without a bottom sash, drilling might be necessary to correctly install a window-type air conditioning unit. The step-by-step guide to properly installing a window aircon is as follows.

  1. Choose the right size and capacity of window air conditioner. Here’s a quick guide to roughly match aircon capacity requirements with room dimensions.

    Room floor area in square feet

    Aircon capacity in BTU

    150 – 350

    5,000 – 8000

    350 – 550

    8,000 – 12,000

    550 – 1,050

    12,000 – 18,5000

    1,050 – 1,600

    18,5000 – 25,000

  2. Measure the height and width of the window opening. Choose the window that has a three-prong power outlet nearby. The outlet must be used to provide power to the AC unit alone. It must also be properly rated for the aircon capacity.

  3. Prepare and measure out the amount of foam insulation around the window. You might also consider putting up a small awning to shield the window aircon from direct sunlight and rain.

  4. Mount the window AC unit. Ensure the window sash is set up as far as it will go and that the air conditioning unit is sufficiently balanced and in a stable position. Screw the sash and attach the L-shaped clips securing the bottom sash frame to the top sash frame.

  5. Use mounting brackets on the outside as well to fully support the weight of the air conditioning unit.

  6. Seal any gaps around the window frame and the aircon. Use whichever is appropriate–foam insulation or sealant. Then apply insulation panels to ensure your window AC runs smoothly throughout.

Aircon installation for a split-type AC unit



For the installation of a centralized air conditioning system, it is best to let HVAC professionals handle it. In general, here’s how a split-type air conditioner is installed.

  1. Plan the placements of both the indoor and outdoor sub-units. If you opted for a system 2 aircon, for example, select where to install the two indoor units and the outdoor unit.

  2. Mark the wall, if you need to drill in order to install mounting plates for the indoor AC unit.

  3. Drill the hole for the pipework and wiring system connecting the outdoor unit with the indoor unit, and run them through the hole. Ensure that the refrigerant pipes are not bent or twisted as they are passed through the drilled hole and into their respective ports on the indoor AC unit. Set up the aircon trunking as well; it will protect the piping and also hide it from view.

  4. Mount and secure the outdoor unit in an open and level ground. The surrounding area must be well ventilated at all times and should be clear of obstructions. It also helps to place the outdoor unit away from direct sunlight and rain. Run the refrigerant pipes and the wiring from the indoor unit ports to their corresponding ports on the outdoor unit.

  5. Vacuum the line and ensure there is no air or moisture inside before you fill it with refrigerant liquid. This step requires special equipment and protective gear, which you may not have. It is highly recommended that you book an appointment with an aircon gas top-up service provider and have an HVAC technician do it for you, in the same way that a thorough aircon overhaul is best left to experts.

  6. Do final checks and test the newly installed air conditioning system if it is running properly and if there are leaks.

Aircon Installation Costs and Considerations in Singapore

Navigating the financial aspects of a new air conditioning system requires an understanding that the unit’s price tag is merely the starting point. The final investment is shaped by a series of interconnected choices and physical realities unique to your home. A thorough grasp of these factors empowers you to allocate your budget effectively, ensuring your investment delivers optimal comfort, efficiency, and value for years to come.

The Core Factors Influencing Installation Cost

The primary determinant of your project’s budget is the type of air conditioning system you select. Split-system units, which pair one outdoor compressor with one or more indoor fan coils, remain the most prevalent and cost-effective solution for residential cooling. For homes requiring simultaneous climate control in several rooms, a multi-split system presents a streamlined alternative, though it necessitates a more powerful outdoor unit. Occupying the premium end of the spectrum, ducted systems provide centralized, concealed cooling through a network of vents, demanding intricate design and a significantly more complex installation process (e.g. Daikin’s centralised cooling system in Tengah). The choice between these systems directly dictates the level of technical expertise, materials, and time required, all fundamental components that define the final aircon installation cost Singapore homeowners ultimately incur.

System Specifications and Brand Value

Technical specifications and manufacturer choice further refine the project’s financial outline. A unit’s BTU (British Thermal Unit) rating, which indicates its cooling capacity, must be precisely calibrated to your room’s dimensions; an undersized unit will labour incessantly, while an oversized one will cool inefficiently through short, frequent cycles. Inverter compressor technology, though commanding a higher initial investment, offers considerable long-term energy savings by modulating its speed rather than constantly switching on and off. Furthermore, established brands renowned for their durability and performance, such as Daikin or Mitsubishi Electric, often reside at a higher price point than emerging competitors. These elements collectively form the hardware portion of any air conditioner installation cost Singapore quotation.

Site-Specific Challenges and Complexities

The physical attributes of your property introduce another critical variable into the costing equation. Installation complexity can fluctuate dramatically. The most economical scenario is a straightforward replacement, where new units occupy the exact positions of old ones, reusing existing and viable piping. A completely new air con installation Singapore project, however, involves extensive work: running fresh copper refrigerant lines, installing new drainage systems, and implementing dedicated electrical wiring. The project’s physical difficulty, such as requiring high-rise scaffolding, drilling through reinforced concrete walls, or covering exceptionally long distances between indoor and outdoor units, will incur additional labour and material fees. Even a seemingly simple window aircon installation Singapore can present unique challenges related to structural support and weatherproofing, which certified technicians must address to ensure safety and prevent water ingress.

Why Professional Installation is a Non-Negotiable Investment

It is important to perceive the installation quote not as a simple fee but as a foundational investment in quality and long-term performance. Engaging accredited and experienced technicians guarantees the work adheres to rigorous safety protocols and manufacturer specifications. A meticulous installation maximizes energy efficiency, which directly curtails monthly utility expenses, and extends the system’s operational lifespan, thereby protecting your capital outlay. It also preempts future aggravations like refrigerant leaks or water damage, which frequently originate from subpar workmanship. When evaluating an aircon installation Singapore price, prioritize comprehensive service proposals that explicitly include premium materials—such as adequately insulated copper pipes and robust mounting brackets—as these components are vital for the system’s integrity and durability.

Making an Informed Decision

Securing multiple detailed quotations is an essential step in the process. Reputable providers will insist on an on-site survey to accurately assess your space before furnishing a transparent, itemized estimate. This allows for a clear comparison of deliverables, including the number of trunking points, the specification of materials, and the comprehensive warranty terms covering both parts and labour. This diligent approach provides a realistic and accurate forecast of the total investment required.

Your home’s comfort is a long-term investment that hinges on a professional and precise installation. Do not leave such a critical component to chance. Contact FixFirst today over Whatsapp to schedule an on-site assessment and receive a detailed, transparent quotation tailored to your specific needs. Ensure your cooling system is installed for peak performance, efficiency, and reliability from day one.

Frequently Asked Questions (FAQs) – Aircon Installation

At FixFirst, we provide professional aircon installation services for a wide range of air conditioning systems. We install the following:

  • Split unit aircon installation
  • Multi-split system installation
  • Ceiling cassette aircon installation
  • Window unit installation
  • Centralized aircon system installation
  • Commercial aircon installation for offices and businesses

Our team is trained to handle installations for both residential and commercial properties, ensuring optimal performance and efficiency.

The cost of aircon installation depends on several factors, including:

  • The type and brand of the aircon unit
  • The complexity of the installation (e.g., single split vs. multi-split systems)
  • Additional requirements like piping, wiring, or structural modifications
  • The size of your property and the number of units to be installed

For a detailed quote, contact us for a free consultation. We provide transparent pricing with no hidden costs.

Yes, we are experienced in installing aircon units from all major brands, including Daikin, Midea, Mitsubishi, Panasonic, LG, Toshiba, Europace, and more. Whether you’ve already purchased a unit or need recommendations, our team can assist you.

The duration of an aircon installation depends on the type of system and the complexity of the job. On average, a single split unit installation takes 2-4 hours while a multi-split system or centralized aircon installation may take 1-2 days. Larger commercial installations may require more time, depending on the scope of the project. But we strive to complete all installations efficiently without compromising on quality.

Aircon installation is a complex process that requires technical expertise, specialized tools, and knowledge of electrical and plumbing systems. Improper installation can lead to poor performance, higher energy bills, or even safety hazards. We strongly recommend hiring professional technicians like FixFirst to ensure a safe and efficient installation.

Before installing an air conditioner, consider the following:

  • Room size. Choose an aircon with the appropriate cooling capacity (measured in BTU).
  • Energy efficiency. Opt for units with higher energy efficiency ratings to save on electricity bills.
  • Placement. Ensure the indoor and outdoor units are installed in optimal locations for airflow and maintenance access.
  • Budget. Factor in the cost of the unit, installation, and long-term maintenance.

Our team can guide you through these considerations to help you make the best decision.

Yes, we offer a warranty on our installation services to ensure your peace of mind. The warranty covers workmanship and any issues arising from the installation process. Specific terms and duration will be provided during the consultation.

Absolutely! We provide safe and eco-friendly removal and disposal services for old aircon units. Our team will dismantle the unit, dispose of it responsibly, and prepare the space for the new installation.

To ensure a smooth installation process, please take the following pre–installation preparatory steps.

  • Clear the area around the installation site (both indoor and outdoor).
  • Inform us of any specific requirements or concerns beforehand.
  • Ensure access to power outlets and water points if needed.

Our team will guide you through any additional preparations during the consultation.

Yes, we provide aircon installation services for all types of properties, including HDB flats, condominiums, landed houses, and commercial buildings. We adhere to all building regulations and guidelines to ensure compliance.

Yes, we offer aircon relocation services. Whether you’re renovating or rearranging your space, our technicians can safely move your aircon unit to a new location. Note that relocation may involve additional costs for piping, wiring, and reinstallation.

Regular maintenance is essential to keep your aircon running efficiently. We recommend:

  • Cleaning or replacing air filters every 1-2 months.
  • Scheduling professional servicing every 3-6 months.
  • Checking for unusual noises or reduced cooling performance.

FixFirst also offers comprehensive aircon maintenance packages to keep your system in top condition.

Professional installation ensures:

  • Proper sizing and placement for optimal cooling.
  • Correct handling of electrical and plumbing connections.
  • Compliance with safety standards and building regulations.
  • Long-term reliability and efficiency of your aircon system.

Booking is easy! You can call or Whatsapp us at 89107700 or email us at admin@fixfirst.sg. Our team will get in touch to schedule a consultation and provide a free quote.

While aircon installation is typically scheduled in advance, we understand that urgent situations may arise. Contact us to discuss your needs, and we’ll do our best to accommodate your request.

Yes, we offer aircon upgrade services to enhance your system’s performance and energy efficiency. Whether you’re upgrading to a newer model or switching to a multi-split system, our team can handle the entire process.

Absolutely! Our relationship with customers doesn’t end after installation. We offer after-installation support, including maintenance services, troubleshooting, and repairs. Feel free to reach out if you have any concerns or questions.

If you have additional questions or need further assistance, don’t hesitate to contact us. At FixFirst, we’re committed to providing top-notch aircon installation services tailored to your needs!
